cuda learning log

~ niyar r barman

this page lives outside my main blog because it is iterative and messy, there are lots of small experiments, benchmarks, and incremental progress that doesn’t fit the “finished post” format. think of it as a lab notebook.

learning cuda (and now triton) from scratch. tracking what works, what doesn’t, and how fast things go.

resources:

contents

nov 11 2025: vec-add

basic vector addition. cpu vs gpu benchmark with 10M elements.

this was day 1 stuff. i just wanted a kernel that ran end-to-end: allocate, copy, launch, time it, and see numbers move. most of the work here was convincing myself that the indexing math was actually correct and i wasn’t silently writing out of bounds.

code: 00_vec_add.cu

the kernel is simple. each thread handles one element:

__global__ void vector_add_gpu(float *a, float* b, float*c, int n){
    int i = blockIdx.x * blockDim.x + threadIdx.x;
    if (i < n){
        c[i] = a[i] + b[i];
    }
}

the global thread index formula:

\[i = \texttt{blockIdx.x} \times \texttt{blockDim.x} + \texttt{threadIdx.x}\]

the if guard prevents out-of-bounds access when N isn’t a perfect multiple of block size.

memory setup follows host → device → compute → device → host pattern:

// allocate on device
cudaMalloc(&da, size);
cudaMalloc(&db, size);
cudaMalloc(&dc, size);

// copy input to device
cudaMemcpy(da, ha, size, cudaMemcpyHostToDevice);
cudaMemcpy(db, hb, size, cudaMemcpyHostToDevice);

// launch kernel
int num_blocks = (N + BLOCK_SIZE - 1) / BLOCK_SIZE;
vector_add_gpu<<<num_blocks, BLOCK_SIZE>>>(da, db, dc, N);
cudaDeviceSynchronize();

the <<<num_blocks, BLOCK_SIZE>>> syntax is cuda’s way of specifying grid and block dimensions. number of blocks needed:

\[\texttt{num\_blocks} = \left\lceil \frac{N}{\texttt{BLOCK\_SIZE}} \right\rceil\]

cudaDeviceSynchronize() waits for the kernel to finish before timing.

implemented:

what i learned:

nov 15 2025: vec-add 3d

extended vec-add to compare 1d vs 3d kernel layouts. same operation, different thread organization.

this was me coming back to the same problem but forcing it into a 3d shape. the goal was less “go faster” and more “do i really understand dim3 and 3d indexing, or am i faking it?”. treating a flat array as (nx, ny, nz) made the indexing formulas click.

code: 01_vec_add_3d.cu

1d kernel is straightforward. one dimension, linear indexing:

__global__ void vector_add_gpu_1d(float *a, float *b, float *c, int n) {
    int i = blockIdx.x * blockDim.x + threadIdx.x;
    if (i < n) {
        c[i] = a[i] + b[i];
    }
}

3d kernel treats the flat array as a 3d volume. each thread gets (i, j, k) coordinates. the linearized index:

\[\texttt{idx} = i + j \cdot n_x + k \cdot n_x \cdot n_y\]
__global__ void vector_add_gpu_3d(float *a, float *b, float *c, int nx, int ny, int nz) {
    int i = blockIdx.x * blockDim.x + threadIdx.x;
    int j = blockIdx.y * blockDim.y + threadIdx.y;
    int k = blockIdx.z * blockDim.z + threadIdx.z;

    if (i < nx && j < ny && k < nz) {
        int idx = i + j * nx + k * nx * ny;
        if (idx < nx * ny * nz) {
            c[idx] = a[idx] + b[idx];
        }
    }
}

launching 3d requires dim3 for both blocks and grid:

dim3 blockSize3D(16, 8, 8);  // 16*8*8 = 1024 threads per block
dim3 num_blocks_3d(
    (nx + blockSize3D.x - 1) / blockSize3D.x,
    (ny + blockSize3D.y - 1) / blockSize3D.y,
    (nz + blockSize3D.z - 1) / blockSize3D.z
);
vector_add_gpu_3d<<<num_blocks_3d, blockSize3D>>>(d_a, d_b, d_c_3d, nx, ny, nz);

implemented:

what i learned:

nov 16 2025: matmul

naive matrix multiplication on gpu. each thread computes one output element.

after vec-add, matmul felt like the natural next thing. it shows up everywhere, and you can’t hide from the O(n³) cost. this is where i started thinking harder about memory access patterns, even though this version is still the simple, non-tiled one.

code: matmul.cu

each thread computes one element of the output matrix. row from A, column from B, dot product:

__global__ void matmul(float* a, float* b, float* c, int n){
    int row = blockIdx.y * blockDim.y + threadIdx.y;
    int col = blockIdx.x * blockDim.x + threadIdx.x;

    if (row < n && col < n){
        float prod = 0.f;
        for (int i = 0; i < n; i++){
            prod += a[row * n + i] * b[i * n + col];
        }
        c[row*n + col] = prod;
    }
}

row * n + i walks along row of A. i * n + col walks down column of B.

matrix multiplication: C = A × B where each element:

\[C_{ij} = \sum_{k} A_{ik} \cdot B_{kj}\]

complexity is O(n³) — each of n² threads does n multiply-adds. simple but not optimal — lots of global memory reads.

2d grid setup maps naturally to matrix structure:

dim3 threadsPerBlock(16, 16);  // 256 threads per block
dim3 numBlocks(
    (n + threadsPerBlock.x - 1) / threadsPerBlock.x,
    (n + threadsPerBlock.y - 1) / threadsPerBlock.y
);
matmul<<<numBlocks, threadsPerBlock>>>(d_a, d_b, d_c, n);

implemented:

what i learned:

nov 22 2025: triton add and softmax

tried triton for the first time. writing gpu kernels in python feels weirdly nice.

this is where i temporarily stepped away from cuda c++ and rewrote the same ideas in triton. add first, then softmax. it was fun to see the same indexing and stability tricks (subtract max) but with nicer ergonomics and masking instead of manual if (idx < n) guards.

code: add.py, softmax.py

triton add kernel looks like this:

@triton.jit
def add_kernel(x_ptr, y_ptr, out_ptr, n_elements, BLOCK_SIZE: tl.constexpr):
    pid = tl.program_id(0)
    block_start = pid * BLOCK_SIZE
    offsets = block_start + tl.arange(0, BLOCK_SIZE)
    mask = offsets < n_elements
    x = tl.load(x_ptr + offsets, mask=mask)
    y = tl.load(y_ptr + offsets, mask=mask)
    output = x + y
    tl.store(out_ptr + offsets, output, mask=mask)

and the softmax kernel:

@triton.jit
def _softmax_kernel(
    out_ptr,
    stride_out,
    x_ptr,
    stride_x,
    cols,
    block_size: tl.constexpr,
    num_warps: tl.constexpr,
):
    row_idx = tl.program_id(0)
    row_start_ptr = x_ptr + (row_idx * stride_x)
    col_offsets = tl.arange(0, block_size)
    input_ptrs = row_start_ptr + col_offsets
    mask = col_offsets < cols
    x = tl.load(input_ptrs, mask=mask, other=float('-inf'))
    x_max = tl.max(x, axis=0)
    safe_x = x - x_max
    numerator = tl.exp(safe_x)
    denominator = tl.sum(numerator, axis=0)
    softmax = numerator / denominator
    tl.store(out_ptr + col_offsets + row_idx * stride_out, softmax, mask=mask)

what i learned:

nov 28 2025: add broadcast

broadcasting addition across tensors of different shapes. adds a 3d tensor (X,Y,Z) with a 2d tensor (X,Y) and a 1d tensor (X).

this one was me coming back again to “shapes i actually see in pytorch”: 3d + 2d + 1d. i had to slow down, draw the shapes on paper, and write out the index formulas by hand before i trusted the kernel. it tied together the 3d indexing from earlier with the kind of broadcasting semantics i use all the time on the python side.

code: add_broadcast.cu

the trick is computing the right index for each tensor rank. for tensors with shapes (X, Y, Z), (X, Y), and (X):

\[\texttt{idx}_3 = x \cdot (Y \cdot Z) + y \cdot Z + z\] \[\texttt{idx}_2 = x \cdot Y + y\] \[\texttt{idx}_1 = x\]
__global__ void add_broadcast(
    const float* __restrict__ a,  // shape (X, Y, Z)
    const float* __restrict__ b,  // shape (X, Y)
    const float* __restrict__ c,  // shape (X,)
    float* out,
    int X, int Y, int Z
){
    int x = blockIdx.x * blockDim.x + threadIdx.x;
    int y = blockIdx.y * blockDim.y + threadIdx.y;
    int z = blockIdx.z * blockDim.z + threadIdx.z;

    if (x < X && y < Y && z < Z){
        int idx3 = x * (Y * Z) + y * Z + z;  // 3d index
        int idx2 = x * Y + y;                 // 2d index (ignores z)
        int idx1 = x;                         // 1d index (ignores y, z)

        out[idx3] = a[idx3] + b[idx2] + c[idx1];
    }
}

__restrict__ tells the compiler these pointers don’t alias, enabling better optimization.

3d grid launch to match the tensor shape:

dim3 block(4, 4, 4);  // 64 threads per block
dim3 grid(
    (X + block.x - 1) / block.x,
    (Y + block.y - 1) / block.y,
    (Z + block.z - 1) / block.z
);
add_broadcast<<<grid, block>>>(d_a, d_b, d_c, d_o, X, Y, Z);

implemented:

what i learned:

nov 29 2025: nvtx profiling

instrumenting cuda code with nvtx markers and profiling with nsight systems.

wanted to actually see where time goes in my matmul code. not just “gpu is fast” but “how much is allocation vs copy vs compute”. nvtx lets you wrap sections of code with named ranges, then nsys picks them up and shows you a breakdown.

code: nvtx_matmul.cu

the idea is simple: push a named range before a section, pop it after. nested ranges work too.

#include <nvtx3/nvToolsExt.h>

void matrixMul(float* A, float* B, float* C, int N) {
    nvtxRangePush("Matrix Multiplication");

    nvtxRangePush("Memory Allocation");
    cudaMalloc(&d_A, size);
    cudaMalloc(&d_B, size);
    cudaMalloc(&d_C, size);
    nvtxRangePop();

    nvtxRangePush("Memory Copy H2D");
    cudaMemcpy(d_A, A, size, cudaMemcpyHostToDevice);
    cudaMemcpy(d_B, B, size, cudaMemcpyHostToDevice);
    nvtxRangePop();

    nvtxRangePush("Kernel Execution");
    matrixMulKernel<<<numBlocks, threadsPerBlock>>>(d_A, d_B, d_C, N);
    cudaDeviceSynchronize();
    nvtxRangePop();

    nvtxRangePush("Memory Copy D2H");
    cudaMemcpy(C, d_C, size, cudaMemcpyDeviceToHost);
    nvtxRangePop();

    nvtxRangePush("Memory Deallocation");
    cudaFree(d_A);
    cudaFree(d_B);
    cudaFree(d_C);
    nvtxRangePop();

    nvtxRangePop();  // end Matrix Multiplication
}

compile with nvtx library linked:

nvcc -o nvtx_matmul nvtx_matmul.cu -lnvToolsExt -lineinfo

then profile with nsys:

nsys profile --trace=cuda,nvtx --stats=true ./nvtx_matmul

the output shows exactly where time goes:

 Time (%)  Total Time (ns)  Instances   Avg (ns)         Range
 --------  ---------------  ---------  -------------  ----------------------
     50.0      125,366,415          1  125,366,415.0  Matrix Multiplication
     50.0      125,357,659          1  125,357,659.0  Memory Allocation
      0.0            3,652          1        3,652.0  Kernel Execution
      0.0            3,330          1        3,330.0  Memory Copy H2D
      0.0              140          1          140.0  Memory Deallocation
      0.0              110          1          110.0  Memory Copy D2H

matrix multiplication is the outer nvtx range that wraps everything, so its time includes all nested ranges. the real story: memory allocation takes ~125ms because the first cudaMalloc triggers cuda context initialization. that’s the cold start cost. actual kernel execution is just ~3.6µs.

implemented:

what i learned:

nov 30 2025: cublas matmul

matrix multiplication using cublas instead of writing my own kernel. sgemm (float32) and hgemm (float16).

after writing naive matmul by hand, i wanted to see what the “real” way looks like. cublas is nvidia’s optimized blas library — it’s what pytorch uses under the hood. the tricky part is cublas assumes column-major (fortran style), but i store matrices row-major (c style). there’s a neat trick to avoid transposing.

code: matmul_cublas.cu

gemm computes:

\[C = \alpha AB + \beta C\]

with α = 1, β = 0 it’s just C = AB.

the column-major workaround: instead of computing C = A × B directly, we compute C^T = B^T × A^T. since:

\[(AB)^T = B^T A^T\]

and our row-major matrices look like their transposes to cublas, passing B first then A gives us the right answer in row-major C:

float alpha = 1.0f, beta = 0.0f;
cublasSgemm(handle, CUBLAS_OP_N, CUBLAS_OP_N,
            N, M, K,           // dimensions
            &alpha,
            d_B, N,            // B first (!)
            d_A, K,            // then A
            &beta,
            d_C, N);           // output

the weird argument order (B before A) is the trick. leading dimensions (N, K, N) match the “inner” dimension of each matrix when viewed column-major.

hgemm is the same but with half precision. uses tensor cores on newer gpus. need to convert float32 inputs to fp16 first:

// convert to half precision
half A_h[M * K], B_h[K * N];
for (int i = 0; i < M * K; i++) {
    A_h[i] = __float2half(A[i]);
}

// hgemm call — same pattern as sgemm
__half alpha_h = __float2half(1.0f), beta_h = __float2half(0.0f);
cublasHgemm(handle, CUBLAS_OP_N, CUBLAS_OP_N,
            N, M, K, &alpha_h,
            d_B_h, N, d_A_h, K,
            &beta_h, d_C_h, N);

// convert result back
for (int i = 0; i < M * N; i++) {
    C_cublas_h[i] = __half2float(C_h[i]);
}

implemented:

what i learned:

dec 7 2025: cuTile vec-add

vector addition using nvidia’s cuTile library. tile-based gpu programming in pure python.

triton showed me you can write gpu kernels without touching c++. cuTile is nvidia’s answer to that. a python DSL that automatically leverages tensor cores and tensor memory accelerators while staying portable across gpu architectures. the key abstraction is tiles: immutable, fixed-size chunks of data that live in registers. arrays live in global memory, tiles don’t. you load tiles from arrays, do math on tiles, store tiles back.

code: vec-add-cutile.py

the kernel uses the @ct.kernel decorator. each block (identified by ct.bid(0)) loads a tile from both input arrays, adds them, and stores the result:

@ct.kernel
def vector_add(a, b, c, tile_size: ct.Constant[int]):
    pid = ct.bid(0)

    a_tile = ct.load(a, index=(pid,), shape=(tile_size,))
    b_tile = ct.load(b, index=(pid,), shape=(tile_size,))

    result = a_tile + b_tile

    ct.store(c, index=(pid,), tile=result)

ct.bid(0) is the block index, same as blockIdx.x in cuda. ct.load grabs a tile from global memory into registers. the index tells it which tile (block), shape tells it how big (must be power of two). tiles are immutable, so a_tile + b_tile creates a new tile result. then ct.store writes it back to global memory.

launching is similar to triton. you specify the grid size and let the library handle the rest:

vec_size = 2**12
tile_size = 2**4

a = cp.random.uniform(-1, 1, vec_size)
b = cp.random.uniform(-1, 1, vec_size)
c = cp.zeros_like(a)

grid_size = (ceil(vec_size / tile_size), 1, 1)

ct.launch(cp.cuda.get_current_stream(), grid_size, vector_add, (a, b, c, tile_size))

grid size is number of tiles needed:

\[\texttt{grid\_size} = \left\lceil \frac{\texttt{vec\_size}}{\texttt{tile\_size}} \right\rceil\]

cupy handles the device arrays. cp.random.uniform creates data directly on gpu, no explicit memcpy needed.

implemented:

what i learned:

dec 8 2025: softmax (naive vs optimized)

back to cuda c++. implemented softmax three ways: cpu, naive gpu, and optimized gpu with shared memory + parallel reduction.

code: softmax.cu

softmax for a row is: subtract max (numerical stability), exponentiate, divide by sum. simple enough, but the gpu implementation matters a lot.

cpu baseline

straightforward triple loop. for each row: find max, compute exp and sum, normalize.

void cpu_softmax(float* input, float* output, int rows, int cols) {
    for (int i = 0; i < rows; i++) {
        float max_val = input[i * cols];
        for (int j = 1; j < cols; j++) {
            if (input[i * cols + j] > max_val) max_val = input[i * cols + j];
        }
        float sum = 0.0f;
        for (int j = 0; j < cols; j++) {
            output[i * cols + j] = expf(input[i * cols + j] - max_val);
            sum += output[i * cols + j];
        }
        for (int j = 0; j < cols; j++) {
            output[i * cols + j] /= sum;
        }
    }
}

naive gpu

one thread per row. each thread loops through all columns sequentially. basically the cpu code but parallelized across rows:

__global__ void gpu_softmax_naive(float* input, float* output, int rows, int cols) {
    int row = blockIdx.x * blockDim.x + threadIdx.x;
    if (row < rows) {
        // same triple loop as cpu, but for one row
        float max_val = input[row * cols];
        for (int j = 1; j < cols; j++) { /* find max */ }
        for (int j = 0; j < cols; j++) { /* exp and sum */ }
        for (int j = 0; j < cols; j++) { /* normalize */ }
    }
}

launch config: <<<(rows + 255) / 256, 256>>>. gets ~25x speedup over cpu. not bad, but each thread does O(cols) work alone. we can do better.

optimized gpu: shared memory + tree reduction

the key insight: instead of one thread per row, use one block per row. 256 threads collaborate on a single row using shared memory.

__global__ void gpu_softmax_optimized(float* input, float* output, int rows, int cols) {
    extern __shared__ float sdata[];
    int row = blockIdx.x;
    int tid = threadIdx.x;
    int blockSize = blockDim.x;

    // step 1: parallel max reduction
    float max_val = -INFINITY;
    for (int j = tid; j < cols; j += blockSize) {
        max_val = fmaxf(max_val, input[row * cols + j]);
    }
    sdata[tid] = max_val;
    __syncthreads();

    // tree reduction for max
    for (int stride = blockSize/2; stride > 0; stride >>= 1) {
        if (tid < stride) sdata[tid] = fmaxf(sdata[tid], sdata[tid + stride]);
        __syncthreads();
    }
    max_val = sdata[0];
    __syncthreads();

    // step 2: parallel exp + sum reduction
    float thrd_sum = 0.0f;
    for (int j = tid; j < cols; j += blockSize) {
        output[row * cols + j] = expf(input[row * cols + j] - max_val);
        thrd_sum += output[row * cols + j];
    }
    sdata[tid] = thrd_sum;
    __syncthreads();

    // tree reduction for sum
    for (int stride = blockSize/2; stride > 0; stride >>= 1) {
        if (tid < stride) sdata[tid] += sdata[tid + stride];
        __syncthreads();
    }
    float sum = sdata[0];
    __syncthreads();

    // step 3: parallel normalize
    for (int j = tid; j < cols; j += blockSize) {
        output[row * cols + j] /= sum;
    }
}

launch config: <<<rows, 256, 256 * sizeof(float)>>>. one block per row, shared memory for reduction.

why tree reduction works

instead of one thread summing 8192 values sequentially, 256 threads each sum ~32 values, then combine results in log₂(256) = 8 steps:

[t0] [t1] [t2] [t3] [t4] [t5] [t6] [t7]  <- 256 partial results
   \  /     \  /     \  /     \  /
   [+]      [+]      [+]      [+]        <- 128 results (step 1)
      \    /            \    /
       [+]               [+]             <- 64 results (step 2)
         \              /
          ...continues...                <- 8 steps total
              [sum]                      <- final answer

sequential: O(n) steps. tree reduction: O(log n) steps with n/2 threads working in parallel.

shared memory

shared memory is ~80x faster than global memory. all threads in a block can read/write to it. perfect for reductions where threads need to share intermediate results. declared with extern __shared__ and allocated at launch time (third kernel parameter).

results (8192 x 8192 matrix)

CPU time:                484.017 ms
GPU Naive time:          16.456 ms (Speedup: 29.41x)
GPU Optimized time:      1.812 ms (Speedup: 267.17x)

Optimized vs Naive:      9.08x faster

implemented:

what i learned:

dec 9 2025: softmax with cuBLAS

tried a different angle on softmax: lean on cuBLAS for the reduction bits (argmax, sum of exps) and use tiny cuda kernels just for the non-linear parts (exp + normalize).

code: softmax_cuBLAS.cu

idea: per-row softmax with numerical stability:

kernels: subtract max + exp, then normalize

two simple kernels, each 1d over the row:

__global__ void sub_max_exp(const float* input, float* output, float max_val, int length){
    int idx = blockIdx.x * blockDim.x + threadIdx.x;
    if (idx < length){
        float val = input[idx] - max_val;
        output[idx] = expf(val);
    }
}

__global__ void normalize(float* data, float sum, int length){
    int idx = blockIdx.x * blockDim.x + threadIdx.x;
    if (idx < length){
        data[idx] = data[idx] / sum;
    }
}

launch config is standard 1d:

const int THREADS = 256;
const int BLOCKS = (cols + THREADS - 1) / THREADS;

each row is processed independently, so for every row:

using cuBLAS for reductions

cuBLAS shines at reductions and vector ops, so instead of writing my own kernel for argmax/sum i just used:

int max_idx = 0;
CHECK_CUBLAS(cublasIsamax(handle, cols, row_in, 1, &max_idx));
max_idx -= 1; // cuBLAS is 1-based

float max_val;
CHECK_CUDA(cudaMemcpy(&max_val, row_in + max_idx, sizeof(float),
                      cudaMemcpyDeviceToHost));

float sum_exp = 0.0f;
CHECK_CUBLAS(cublasSasum(handle, cols, row_out, 1, &sum_exp));

this keeps the math in highly-optimized library code and lets my custom kernels stay tiny and easy to reason about.

verification + numerics

used the same cpu softmax as a reference and compared every element:

also manually checked that the first row sums to ~1.0 on the gpu result (good sanity check for softmax).

results (128 x 128 matrix)

Initializing 128 x 128 matrix with random values...
Verifying results...
Results match! Softmax implementation is correct.
Sum of first row softmax (GPU): 1.000000

implemented:

what i learned:
